62 Comments on “SPJS Upload for SharePoint: Custom upload page for uploading documents to various document libraries in a site collection”

1. Hi Alexander,
   Thanks!!!

   When I upload the script to the source editor of the HTML form web part, i get an error: “Cannot retrieve properties at this time”.

   Am i missing something?

   Log in to Reply

   1. This has nothing to do with this script I think, try using compatibility mode in the browser. You can also add the script to a file and link it from a Content Editor Web Part using the content link option.

      Alexander

      Log in to Reply

      1. HI Alexander,
         It worked with CEWP!.
         Thanks so much.
         Gilbert

      2. HI,

         To add to my earlier post:
         It worked with Firefox.
         Didn’t work with IE (I am not getting the ‘submit’ button).

         It didn’t work with Chrome. Gives the following error:
         “Ensure the selected destination exists!
         Error message: undefined”

         Gilbert

      3. Thanks for the feedback. Could you send me some details on the upload target URL. It may be a problem with how chrome interprets the URL.
         Alexander

2. Hi,

   I have implements as described, however I still see the following error even though I am using Internet Explorer 11:

   Your browser is not supported!
   Use Internet Explorer 10 or another modern browser.

   Log in to Reply

   1. Hi,
      I suspect you have compatibility mode activated? In the browser, go to “Tools” > “Compatibility View Settings” and ensure the site is not listed there.

      Alexander

      Log in to Reply

      1. No sites listed in Compatibility view settings.

         I also checked the site in Google Chrome (Version 31.0.1650.63 m) and experienced the same issue.

   2. Use f12 and look at the Document mode and the User agent string:


      Ensure they are NOT below IE 10.

      Which version of SharePoint are you running?

      Alexander

      Log in to Reply

      1. SharePoint 2010 (14.0.7015.1000)

         F12 Settings are:

         Document Mode: 8 (Default)
         User Agent String: Default

         This is strange because there are definitely no Compatibility mode sites and the ‘Display Intranet Sites in Compatibility view’ setting is not ticked!

      2. The problem is that SharePoint forces this document mode in the master page.

         Does it work if you change it to IE10? – still strange that Chrome did not work though…

         Alexander

      3. Doesn’t change if I change it to ’10’ for either the Document Mode or the Agent String

      4. This is strange,
         Can someone else post their experience with it – does it work for you?

         Alexander

3. Hello Alex,

   How much file size we can Upload in Document Library .

   Thanks
   deepak chauhan

   Log in to Reply

   1. reply ?

      Log in to Reply

   2. Hi,
      I do not know how large files you can upload – I have tested whit 15MB files with no problems.

      Please stop nagging for answers after 10 minutes.

      Alexander

      Log in to Reply

4. Hii Alex ,

   i have create the custom list with Relpath column and Title column and give the path(https://rahulinfotech.sharepoint.com/DocLib) in Relpath column but the error shows like below

   Ensure the selected destination exists!

   Error message: The Copy web service method must be called on the same domain that contains the destination url.

   Thanks
   Deepak C

   Log in to Reply

   1. Hi,
      The column name is case sensitive and must be “RelPath” with capital P.

      Alexander

      Log in to Reply

      1. Hii,

         I have use the RelPath but the problem is over there when we select the file then the Upload to option is blank ie List is not connected

         Thanks
         Deepak C

      2. Ensure you have the correct list name in the argument “listName” in the function call to “spjs.upload.getUploadDestinations”.

         Alexander

5. Hii Alex,

   “listName” in the function call to “spjs.upload.getUploadDestinations”. is correct i am sending you a mail please check it

   Thanks
   Deepak C

   Log in to Reply

6. $(document).ready(function () {
   test();
   });

   /******************************************************
   Do not change anything below this line
   *******************************************************/

   function test() {
   var spjs = spjs || {};

   spjs.upload = {
   “version”: “1.0”,
   “versionDate”: “December 8, 2013”,
   “data”: { “fileDataStr”: “” },
   “handleFileSelect”: function (evt) {

   var files = evt.target.files, file = files[0], reader;
   if (files && file) {
   reader = new FileReader();
   reader.onload = function (readerEvt) {
   var binaryString = readerEvt.target.result;
   spjs.upload.data.fileDataStr = binaryString.substring(binaryString.indexOf(“,”) + 1);
   $(“#uploadFileBtn”).show();
   };
   reader.readAsDataURL(file);
   }
   },
   “submitFile”: function () {
   if ($(“#fileUploadTo”).val() === “”) {
   $(“#fileUploadTo”).addClass(“spjs_empty”);
   return;
   } else {
   $(“#fileUploadTo”).removeClass(“spjs_empty”);
   }
   var filePath, fileName, destination, b;
   filePath = $(“#filePicker”).val();
   fileName = filePath.substring(filePath.lastIndexOf(“\\”) + 1);
   destination = location.protocol + “//” + location.host + $(“#fileUploadTo”).val() + “/” + fileName;
   b = [];
   b.push(“”);
   b.push(“”);
   b.push(“”);
   b.push(“” + fileName + “”);
   b.push(“”);
   b.push(“” + destination + “”);
   b.push(“”);
   b.push(“”);
   b.push(“”);
   b.push(“”);
   b.push(“” + spjs.upload.data.fileDataStr + “”);
   b.push(“”);
   b.push(“”);
   b.push(“”);
   $.ajax({
   url: “/_vti_bin/copy.asmx”,
   beforeSend: function (xhr) { xhr.setRequestHeader(“SOAPAction”, “http://schemas.microsoft.com/sharepoint/soap/CopyIntoItems”); },
   type: “POST”,
   dataType: “xml”,
   data: b.join(“”),
   complete: spjs.upload.processResult,
   contentType: “text/xml; charset=\”utf-8\””
   });
   },
   “processResult”: function (data, status) {
   var errorCode, errorMessage;
   errorCode = $(data.responseText).find(“CopyResult”).attr(“ErrorCode”);
   errorMessage = $(data.responseText).find(“CopyResult”).attr(“ErrorMessage”);
   if (errorCode !== “Success”) {
   $(“#uploadFileBtn”).fadeOut(400, function () {
   $(“#uploadError”).html(“Ensure the selected destination exists!Error message: ” + errorMessage).show();
   setTimeout(function () {
   $(“#uploadError”).fadeOut();
   $(“#fileUploadTo”).val(“”);
   $(“#uploadFileBtn”).fadeIn();
   }, 10000);
   });
   } else {
   $(“#uploadFileBtn”).attr(“disabled”, “disabled”).val(“File successfully uploaded”);
   setTimeout(function () {
   $(“#uploadFileBtn”).fadeOut(400, function () {
   $(this).removeAttr(“disabled”).val(“Submit”);
   })
   }, 3000);
   $(“#filePicker”).val(“”);
   }
   },
   “getUploadDestinations”: function (args) {
   var res, q, b;
   b = [“Select destination”];
   q = “”;
   res = spjs_QueryItems({ “listName”: args.listName, “listBaseUrl”: args.listBaseUrl, “query”: q, “viewFields”: [args.friendlyNameField, args.relPathField] });
   $.each(res.items, function (i, item) {
   b.push(“” + item[args.friendlyNameField] + “”)
   });
   $(“#fileUploadTo”).html(b.join(“”));
   }
   };

   if (window.File && window.FileReader && window.FileList && window.Blob) {
   document.getElementById(‘filePicker’).addEventListener(‘change’, spjs.upload.handleFileSelect, false);
   } else {
   $(“#filePicker”).hide().next().show();
   $(“#fileUploadTo”).hide();
   }
   }

   File

   Your browser is not supported!Use Internet Explorer 10 or another modern browser.

   Upload To

   Select destinationFolder 1Folder 2

   When We debug the script so that the spjs.upload.submitFile() is undefined so reply me as soon as possible

   Log in to Reply

   1. It seems you have modified the code and I cannot support you based on this snippet. Is it working with the original, unmodified code?

      Alexander

      Log in to Reply

7. Hello Alex,

   How we can upload multiple file in you script and shows these file into below if you have time please send me the code it’s very urgent for me……….

   Thanks
   Deepak chauhan

   Log in to Reply

   1. Sorry, but I have not built in support for uploading multiple files.
      Alexander

      Log in to Reply

8. Hello Alex,

   How can i show the select file in below of submit button

   Thanks
   Deepak chauhan

   Log in to Reply

9. Hi, I have tried this and received the same error as someone else above. The submit button does not appear.

   Log in to Reply

   1. What kind of error are you getting?

      Alexander

      Log in to Reply

      1. The submit button doesn’t appear once the js file has been added.

      2. The submit button will not show until you have loaded a file in the field.

         Alexander

10. Hi Alexander,

    I’ve tried your code and works marvelous, I still have one question though, let’s say that my documents library has a field called “special Id” which I have stored in a SQL database and I’m getting information listed from SQL in my webpage, is it possible to take this “special Id” into the upload document function so the value get’s stored each time a user uploads a document?

    Thanks in advance for your help!
    Carlos

    Log in to Reply

    1. Hi,
       You should be able to add extra fields to the upload code. Change these lines:

       b.push("<Fields>");
       b.push("<FieldInformation Type='Text' DisplayName='Title' InternalName='Title' Value='"+fileName+"' />");
       b.push("</Fields>");

       like this:

       b.push("<Fields>");
       b.push("<FieldInformation Type='Text' DisplayName='Title' InternalName='Title' Value='"+fileName+"' />");
       b.push("<FieldInformation Type='Text' DisplayName='Your field name' InternalName='YourFieldInternalName' Value='"+the_variable_with_the_id+"' />");
       b.push("</Fields>");

       Alexander

       Log in to Reply

       1. Thsnk you!! Works great

11. Pingback: Custom form for adding list item with attachments | SharePoint JavaScripts

12. var spjs = spjs || {};

    spjs.upload = {
    “version”:”1.0″,
    “versionDate”:”December 8, 2013″,
    “data”:{“fileDataStr”:””},
    “handleFileSelect”:function(evt){
    var files = evt.target.files, file = files[0], reader;
    if(files && file){
    reader = new FileReader();
    reader.onload = function(readerEvt) {
    var binaryString = readerEvt.target.result;
    spjs.upload.data.fileDataStr = binaryString.substring(binaryString.indexOf(“,”)+1);
    $(“#uploadFileBtn”).show();
    };
    reader.readAsDataURL(file);
    }
    },
    “submitFile”:function() {
    if($(“#fileUploadTo”).val() === “”){
    $(“#fileUploadTo”).addClass(“spjs_empty”);
    return;
    }else{
    $(“#fileUploadTo”).removeClass(“spjs_empty”);
    }
    var filePath, fileName, destination, b;
    filePath = $(“#filePicker”).val();
    fileName = filePath.substring(filePath.lastIndexOf(“\\”)+1);
    destination = location.protocol+”//”+location.host+”/clientes/excondemo/Control%20de%20Documentos/”+fileName;
    b = [];
    b.push(“”);
    b.push(“”);
    b.push(“”);
    b.push(“” + fileName + “”);
    b.push(“”);
    b.push(“”+destination+””);
    b.push(“”);
    b.push(“”);
    b.push(“”);
    b.push(“”);
    b.push(“”+spjs.upload.data.fileDataStr+””);
    b.push(“”);
    b.push(“”);
    b.push(“”);
    $.ajax({
    url: “/_vti_bin/copy.asmx”,
    beforeSend: function (xhr) { xhr.setRequestHeader(“SOAPAction”, “http://schemas.microsoft.com/sharepoint/soap/CopyIntoItems”); },
    type: “POST”,
    dataType: “xml”,
    data: b.join(“”),
    complete: spjs.upload.processResult,
    contentType: “text/xml; charset=\”utf-8\””
    });
    },
    “processResult”:function(data, status) {
    var errorCode, errorMessage;
    errorCode = $(data.responseText).find(“CopyResult”).attr(“ErrorCode”);
    errorMessage = $(data.responseText).find(“CopyResult”).attr(“ErrorMessage”);
    if(errorCode !== “Success”){
    $(“#uploadFileBtn”).fadeOut(400,function(){
    $(“#uploadError”).html(“Ensure the selected destination exists!Error message: “+errorMessage).show();
    setTimeout(function(){
    $(“#uploadError”).fadeOut();
    $(“#fileUploadTo”).val(“”);
    $(“#uploadFileBtn”).fadeIn();
    },10000);
    });
    }else{
    $(“#uploadFileBtn”).attr(“disabled”,”disabled”).val(“File successfully uploaded”);
    setTimeout(function(){
    $(“#uploadFileBtn”).fadeOut(400,function(){
    $(this).removeAttr(“disabled”).val(“Submit”);
    })
    },3000);
    $(“#filePicker”).val(“”);
    }
    }
    };

    this is my code…. it’s works but the file is empty in librery with out data inside.

    Log in to Reply

    1. Hi,
       Did you modify the code, or is it my original version from the article?

       Which browser are you using?

       Alexander

       Log in to Reply

       1. It’s the original code but was modified to obtain the library manually.

       2. Is it the same error for all field types? – and please let me know which browser you use.

          Alexander

       3. I misspelled – I meant FILE types – is this what you meant also?

          Can you hit F12 in IE and tell me the document mode and user agent string that shows in the bottom button in the left side of the developer console.

          Alexander

13. All fields have the same problem. I use IE 11.

    Log in to Reply

14. I also meant files.
    Document mode: 5
    User agent string: default

    Log in to Reply

    1. OK – Good,
       The problem may be the document mode. I’m not sure why this document mode is applied, but try changing it to 10 – and also the user agent string to 10.

       Do you have other code that could force this document mode? – it refers to IE v5 from 1999…

       Alexander

       Log in to Reply

15. i tried changing both.. but the same problem.

    Log in to Reply

16. b.push( + spjs.upload.data.fileDataStr + );

    this line contains the information?

    Log in to Reply

    1. Yes

       Log in to Reply

17. this line dont work…. my files is empty

    Log in to Reply

    1. Hi,
       I’m sorry, but there is not much more I can do. Try another browser, or move the code to another page to see if this helps. Remove any additional code that could interfere.

       I hope you figure it out.
       Alexander

       Log in to Reply

18. Totally confused. Are there two scripts to load? The getUploadDestination script is not anywhere in the list of js files–…”Get the file “spjs-utility.js” from here”

    $(document).ready(function(){
    spjs.upload.getUploadDestinations({
    “listName”:”UploadDestination”,
    “listBaseUrl”:””,
    “friendlyNameField”:”Title”,
    “relPathField”:”RelPath”,
    “orderByField”:”Title”
    });

    Log in to Reply

    1. The “second” script is in the article – in the code block.

       Alexander

       Log in to Reply

19. What if I have additional data fields in the Document library that I want to update when this file is loaded … can this be done as well with this code? The fields may be i.e. Material Type, etc.

    Log in to Reply

    1. Look at this comment: https://spjsblog.com/2013/12/08/spjs-upload-for-sharepoint-custom-upload-page-for-uploading-documents-to-various-document-libraries-in-a-site-collection/#comment-59464

       Alexander

       Log in to Reply

20. I have the following code implementing and I do not understand what format I need to enter in for the value.. please assume I am only interested in one specific Document Library so this value can be hard-coded… the URL for my DEV environment is

    http://itsusmpw00799:56789/prd/hcctesting/PharmSLT_Meetings_Materials/Forms/AllItems.aspx

    I am struggling to get this work.

    What other pieces of code need to be customized to get this to work and what references to JS do I need if all the scripts are emebedded?

    Log in to Reply

    1. Hi,
       Did you get the original version to work before trying to modify it?

       Alexander

       Log in to Reply

21. Can you explain why you took a substring of the file reader output in the line “spjs.upload.data.fileDataStr = binaryString.substring(binaryString.indexOf(“,”)+1);”

    I ask because I’m trying to figure out why the solution does not work for Microsoft PowerPoint files using IE10 and SP2010 at my workplace. I have no issues on my own SP2010 website using IE11.

    Log in to Reply

    1. This is done to strip off the part to the left of the comma – like this example string for an image:


       Alexander

       Log in to Reply

       1. Got it, thanks Alex!

22. Hi Alex, thanks for sharing this brilliant work! I’m in the process of testing the above solution for our intranet with multiple document libraries. Few things that I would love to know is:
    1. How can we force reset the ‘File Select’ & ‘Upload Destination’ fields after every instance regardless of final outcome?
    2. How can we get prompted to populate ‘REQUIRED’ metadata following the successful file upload? – Basically the file upload function works flawlessly but would love to see the EDIT properties form prompted to force the users to do the right thing & check-in.
    3. Bit over optimistic – I’ve noticed that spjs-utility.js has functions to call CASCADED drop-downs. Could we use this to perform selective lookup? Say, you choose a upload destination ‘Restricted’ upon which, 3rd field called ‘Choose’ with dropdown choices say HR / Finance / Corporate should become available. Correct me if I’ve wrong assumption. Really appreciate your time and help. Cheers!

    Log in to Reply

23. Hi,
    1: You can reset the upload to by changing the function “processResult” and adding this to the “success” function. See the “error” function a few lines up for reference.

    $("#fileUploadTo").val("");

    2: This is currently not built in, but you can add something like this to the “success” function in “processResult” – after this line:

    $("#uploadFileBtn").attr("disabled","disabled").val("File successfully uploaded");

    var fileDir = $(data.responseText).find("CopyResult").attr("DestinationUrl");
    var fileMetadata = spjs.utility.queryItems({"listName":$("#fileUploadTo option:selected").text(),"query":"<Where><Eq><FieldRef Name='EncodedAbsUrl' /><Value Type='Text'>"+fileDir+"</Value></Eq></Where>","scope":"RecursiveAll","viewFields":["FileLeafRef","FileDirRef"]})
    if(fileMetadata.count > 0){
        var id = fileMetadata.items[0].ID;
        var path = fileMetadata.items[0].FileDirRef.split(";#")[1];
        SP.UI.ModalDialog.showModalDialog({"url":makeAbsUrl("/"+path+"/Forms/EditForm.aspx?ID="+id)});
    }

    Please note that this will not work in SP2007 as the “showModalDialog” function is not built in.

    Also note that this code example will only work if:
    * You use the display name of the document library in the “option text” / Title in the <select>
    * Your document library is in the same site as the upload control.

    3: The cascaded dropdown solution I have created is for SharePoint forms and cannot be used here.

    Unfortunately I don’t have time to add this functionality, but as you have access to he actual <select> in the code you can build your own cascading logic if you like – you are free to alter the code if you want to give it a go.

    You can also add the destinations manually as <option> in the <select> – and you can use <optgroup> to group the different destinations.

    Alexander

    Log in to Reply

24. Alex, brilliant! really appreciate your time and help.

    The file edit form.aspx following the file upload worked great! in my SP O365 test site collection as I had the list names and config exactly to meet the requirements in your response to pt.2. Also, EditForm in Upload mode (Mode=Upload) works just a treat as it allows to CheckIn the file.

    SP.UI.ModalDialog.showModalDialog({“url”:makeAbsUrl(“/”+path+”/Forms/EditForm.aspx?Mode=Upload&ID=”+id)})

    But, in our production SP O365, I have a DestinationList created as per your guidance in this article. Again, it works great for file upload. I’m failing to get EditForm.aspx following the upload. In relation to this:
    a. will the above code (your reply to pt.2) work if there is a space in the destination library name? I’ve confirmed the Display name = Library Name. As an example we have a document library called ‘Information Technology’ and ‘Human Resources’
    b. if we have a secured folder with-in a library with different permission and if I’m using the ‘Select Destination’ list to define the file upload path then, unfortunately, as you have pointed out, I cant get the editform.aspx using the above method. So, wondering if there is any other ways to achieve the same result?
    Can we somehow obtain the URL & ID of recently uploaded file by reverse lookup and then pass them to EditForm.aspx? Was thinking something along SPServices.SPGetLastItemID!?
    Again, appreciate your time. Your articles are very helpful for many SharePoint Admins like myself.
    cheers

    Log in to Reply

    1. See what you can make of the updated code in the article. Please note that you must change your list / config – see change log and read trough the article.

       Alexander

       Log in to Reply

25. Hi Alex,
    is it possible to have two upload fields at single page?
    The usecase is that there are no “select destination” section but fixed. One upload field saves files to one document library, second upload field saved different type of document to another document library.
    Thanks
    Michal

    Log in to Reply

    1. I looked at the code and it doesn’t look like this will be possible because the html controls ID is not adapted for using multiple instances in one page.

       You can try modifying the code to add a parameter “instanceID”:”an_unique_string” in the argument passed to the function, and then appending this string to all the ID’s – like “uploadFileBtn” to ensure all controls are unique even if you add the function multiple times.

       Alexander

       Log in to Reply

This site uses Akismet to reduce spam. Learn how your comment data is processed.
