No option to hide "ID" on ediform.aspx & problems with overlay (18 October 2015)

Forums Dynamic Forms for SharePoint No option to hide "ID" on ediform.aspx & problems with overlay (18 October 2015)

This topic contains 3 replies, has 2 voices, and was last updated by  AdamP 2 years ago.

  • Author
    Posts
  • #8880

    AdamP
    Participant

    I’ve just done a fresh install of DFFS (18 October 2015 version)
    DFFS Frontend 4.358
    DFFS backend 4.357
    spjs-utility version: 1.253
    jQuery 1.11.3
    vLookup Frontent 2.253
    SP2010 Standard

    There are two things I’ve come across which seem a bit strange.
    1) On editform on a document library I don’t see the option to do anything with the ID field – I wanted to hide it, but there is no entry in the dropdowns on the rules tab, and “ID” doesn’t appear in the Field Table tab as a valid field.
    On dispform, it functions exactly as expected – ID field in field table and in the dropdown menus.

    2) DFFS frontend overlay seems to be causing an issue with the form while being edited – white box in front of everything else on the form – see attachment.
    Inspection of this area with developer tools shows

    <DIV id=dffs_formTableOverlay style="CURSOR: default; HEIGHT: 100%; WIDTH: 100%; POSITION: absolute; Z-INDEX: 9999; BACKGROUND-COLOR: #ffffff">&nbsp;</DIV>

    I’ve not seen this before when setting up DFFS.

  • #8885

    AdamP
    Participant

    I’m also seeing errors in the console (for both dispform and editform – both refer to editform.aspx);



    SCRIPT70: Permission denied
    File: EditForm.aspx, Line: 19, Column: 1

    Which is the document.write line after CDATA



    // <![CDATA[
    document.write('<script type="text/javascript" src="/_layouts/1033/init.js?rev=BjQJs0OCQh3Zfydsdw2MYw%3D%3D"></' + 'script>');
  • #8908

    Alexander Bautz
    Keymaster

    Hi,
    Thanks for the feedback. I’ll add the ID as selectable in EditForm – it went missing in one of the previous *fixes*.

    The overlay is also a change in one of the lates releases to try to prevent a flash of the unformatted form before DFFS kicks in – I’ll add a fix to the next release, but you can use this code in the overlay CEWP:

    <div id="dffs_formTableOverlay" style="width:100%;height:100%;background-color:#ffffff;position:absolute;z-index:9999;cursor:default;"> </div>

    <script type="text/javascript">
    if(document.forms[MSOWebPartPageFormName].MSOLayout_InDesignMode.value !== "1"){
    	(function(){
    		var div = document.createElement('div'), o = document.getElementById("dffs_formTableOverlay");
    		div.id = "dffs_loadingOverlay";
    		// Change this to have your own overlay message
    		div.innerHTML = "DFFS is loading...";
    		document.body.insertBefore(div, document.body.firstChild);
    		if(o !== null){
    			o.parentElement.removeChild(o);
    		}
    		setTimeout(function(){
    			var oDiv = document.getElementById("dffs_loadingOverlay");
    			if(oDiv !== null){
    				oDiv.innerHTML = "<span style='font-size:20px'>This took forever!<span style='font-size:12px'><br><br>Click to close this overlay.</span></span>";
    				oDiv.onclick = function(){
    		   			this.parentNode.removeChild(this);
    				};
    			}
    		},10000);
    	})();
    }else{
    	var o = document.getElementById("dffs_formTableOverlay");
    	if(o !== null){
    		o.parentElement.removeChild(o);
    	}
    }
    </script>

    The last error you posted is not known to me, and this script is not used in my code.

    Alexander

  • #8914

    AdamP
    Participant

    You’re quite right Alexander, the last error seems to be an issue specific to the site collection I was testing in – as yet unresolved, but nothing at all to do with DFFS.

    In production I’m still running a previous version of DFFS so I’ve still got the older code for the overlay (no flicker issues experienced).

    Adam
